Sunlight Readable Display Module (CS-100 Series)
CS-100 Series is the Sunlight Readable Display Module with projected capacitive touch screen. It offers resolution up to 1920 x 1080 (Full HD) and high brightness up to 1800 nits. It supports flat surface and IP65 dust / waterproof front panel. CS-100 Series is a rugged and reliable solution with aluminum die-casting front frame dedicating to sunlight / outdoor industrial applications.Product | Model Name | LCD Size | Brightness | Touch Type | Resolution |
---|---|---|---|---|---|
![]() | CS-108 | 8.4" TFT-LCD (4:3) | 1600 nits | Capacitive | 800x600 (SVGA) |
![]() | CS-110H | 10.4" TFT-LCD (4:3) | 1500 nits | Capacitive | 1024x768 (XGA) |
![]() | CS-112H | 12.1" TFT-LCD (4:3) | 1500 nits | Capacitive | 1024x768 (XGA) |
![]() | CS-115 | 15" TFT-LCD (4:3) | 1800 nits | Capacitive | 1024x768 (XGA) |
![]() | CS-117 | 17" TFT-LCD (5:4) | 1500 nits | Capacitive | 1280x1024 (SXGA) |
![]() | CS-119 | 19" TFT-LCD (5:4) | 1600 nits | Capacitive | 1280x1024 (SXGA) |
NEW ![]() | CS-W115FH | 15.6" TFT-LCD (16:9) | 1200 nits | Capacitive | 1920x1080 (Full HD) |
![]() | CS-W121 | 21.5" TFT-LCD (16:9) | 1000 nits | Capacitive | 1920x1080 (Full HD) |
![]() | CS-W124 | 24" TFT-LCD (16:9) | 1500 nits | Capacitive | 1920x1080 (Full HD) |
