Embedded MXM GPU Computer (GM Series)
GM Series is a rugged, compact, and high-performance GPU computer with embedded GPU expansion capability. It supports Intel® Xeon®/Core™ socket type processors and Mobile PCI Express Module (MXM 3.1 Type A/B form factor) in a small footprint (260 mm x 200 mm x 85). It is ideal for applications requiring high GPU processing power and to be installed in space-limited environments.Product | Model Name | CPU | GPU | I/O | Expansion |
---|---|---|---|---|---|
NEW ![]() | GM-1100 | Intel® 14/13/12th Gen Core™ i9/i7/i5/i3 Processors | 1x MXM Carrier Board Socket for MXM GPU Module Expansion | 1x DisplayPort 1x HDMI 1x VGA 1x 2.5GbE LAN 1x 1GbE LAN 4x COM 1x 20Gbps USB3.2 Gen2 3x 10Gbps USB3.2 Gen2 4x 5Gbps USB3.2 Gen1 | 1x CFM Interface 2x CMI Interface 2x SIM Socket 1x M.2 Key E Type 2230 Socket 1x M.2 Key B Type 3042/3052 Socket 2x M.2 Key B Type 2242 Socket |
![]() | GM-1000 | Supports 9/8th Generation Intel® Xeon® / Core™ LGA1151 Socket Type Processors | 1x MXM Carrier Board Interface for MXM3.1 Type A / Type B Expansion | 1x DVI-I 1x DisplayPort 1x HDMI 2x GbE LAN 4x COM 4x USB 3.2 Gen2 4x USB 3.2 Gen1 | 1x CFM Interface 2x CMI Interface 3x Full-size Mini-PCIe Sockets 2x SIM Socket 1x M.2 E Key Socket (CNVi) 1x M.2 M Key Socket (NVMe) |
