High Performance Open Frame Panel PC (CO-100/P2000 Series)

High Performance Open Frame Panel PC (CO-100/P2000 Series)

Cincoze’s high-performance open-frame modular panel PCs (CO-100/P2000 series) use Intel® Core U series processors that provide high-performance data processing and graphics computing capabilities with only 15W low power consumption. The CO-100/P2000 series supports CFM technology that extends system functions according to requirements, with options such as Power Ignition Sensing (IGN) and Power over Ethernet (PoE). The series has multiple sizes, display ratios (5:4 and 16:9), and touchscreen options. Its integrated structure, exclusive adjustable mounting bracket, and support for multiple mounting methods to perfectly fit cabinets of different materials and thicknesses. The robust design also meets the application needs of harsh industrial environments.
ProductModel NameDisplayCPUI/OExpansion
CO-119C / P2202 SeriesCO-119C / P2202 Series19" TFT
1280x1024 (5:4)
Intel® Core™ i5-1245UE
Intel® Core™ i3-1215UE
1x VGA
1x DisplayPort
1x HDMI
2x GbE LAN
4x USB
4x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
1x M.2 Key E Type 2230 Socket, Support Intel CNVi/Wireless Module
CO-119C / P2102 SeriesCO-119C / P2102 Series19" TFT
1280x1024 (5:4)
Intel® Core™ i5-8365UE
Intel® Core™ i3-8145UE
1x VGA
1x DisplayPort
2x GbE LAN
5x USB
4x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN) 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module
CO-119C / P2002 SeriesCO-119C / P2002 Series19" TFT
1280x1024 (5:4)
Intel® Core™ i5-6300U
Intel® Core™ i3-6100U
1x VGA
1x DVI-D
2x GbE LAN
5x USB
6x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
CO-W121C / P2202 SeriesCO-W121C / P2202 Series21.5" TFT
1920x1080 (16:9)
Intel® Core™ i5-1245UE
Intel® Core™ i3-1215UE
1x VGA
1x DisplayPort
1x HDMI
2x GbE LAN
4x USB
4x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
1x M.2 Key E Type 2230 Socket, Support Intel CNVi/Wireless Module
CO-W121C / P2102 SeriesCO-W121C / P2102 Series21.5" TFT
1920x1080 (16:9)
Intel® Core™ i5-8365UE
Intel® Core™ i3-8145UE
1x VGA
1x DisplayPort
2x GbE LAN
5x USB
4x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module
CO-W121C / P2002 SeriesCO-W121C / P2002 Series21.5" TFT
1920x1080 (16:9)
Intel® Core™ i5-6300U
Intel® Core™ i3-6100U
1x VGA
1x DVI-D
2x GbE LAN
5x USB
6x COM
16x DIO
2x Full Size Mini-PCIe Socket and Support CFM (PoE, IGN)
