CS-117 / P2002E

17" TFT-LCD Sunlight Readable Touch Panel PC with 6th Gen. Intel® Core™ Processor

PRODUCTS FEATURES
  • 17” TFT-LCD with Ultra High Brightness up to 1,500 nits and 1280 x 1024 (SXGA) Resolution
  • Onboard Intel® 6th Generation Core™ Processor U Series (15W)
  • Supports 2x DDR4 SO-DIMM Socket, up to 32 GB
  • Integrated Intel® HD Graphics 520, Triple Display Support
  • 2x 2.5” SATA Drive Bay, 1x mSATA, and 1x CFast Socket
  • Rich I/O (2x GbE LAN, 6x COM, 5x USB, 16x Isolated DIO)
  • 2x Full-size Mini-PCIe Socket for Wireless and I/O Expansion
  • Wide Range Operating Temperature -20°C to 70°C
  • Designed with Aluminum Die-casting Front Frame
  • True Flat IP65 Front Panel Protection
  • Supports Panel / VESA / Rack Mounting
  • Convertible Display System (CDS) Technology Supported
OVERVIEW
CS-117/P2000 Series is a 17" TFT-LCD sunlight readable touch panel PC offering 1,500 nits ultra high brightness and 1280 x 1024 (SXGA) resolution. The system is equipped with high-performance Intel® 6th generation Core™ U series processor and provides extensive I/O including 2x GbE, 5x USB, 6x RS232/422/485, 8x DI/8x DO, 1x VGA and 1x DVI-D. It also supports 2x Mini-PCIe slot and 1x SIM socket for a variety of wireless connections, such as BT/WiFi and 3G/LTE. In addition, there are 3 types of storage devices including 2.5" SATA HDD (RAID 0/1), mSATA and CFast. The accessible design of these storage devices allows quick data access and easy maintenance.

CS-117/P2000 Series supports Convertible Display System (CDS) technology. Comparing to regular standalone panel PCs, it can lower maintenance cost and reduce unplanned downtime. For greater flexibility, CS-117/P2000 Series has PCI/PCIe expandable version and PoE/power ignition functions by additional CFM (Control Function Module). Furthermore, CS-117/P2000 Series is a truly rugged display system supporting wide range operating temperature (-20°C to 70°C), IP65 dust/waterproof front panel, wide range DC power input (9 to 48VDC) and rigorous industrial protections.
SPECIFICATION
Model NameCS-117/P2002E
Model No.CS-117C/P2002E
DisplayLCD Size17" (5:4)
Max. Resolution1280 x 1024
Brightness (cd/m2)1500
Contrast Ratio800 : 1
LCD Color16.7M
Pixel Pitch (mm)0.264 (H) x 0.264 (V)
Viewing Angle (H-V)160 / 140
Backlight MTBF50,000 hrs (LED Backlight)
TouchResistive 5-wire-
Projected CapacitiveV
Processor SystemOnboard 6th Intel® Core™ U processors (Skylake)
- Intel® Core™ i5-6300U processor (3M Cache, up to 3.00 GHz)
- Intel® Core™ i3-6100U processor (3M Cache, 2.30 GHz)
- TDP: 15 W
- BIOS: AMI 64Mbit SPI BIOS
Memory2x DDR4 260-pin SO-DIMM socket, support up to 32 GB
(2133MHz, un-buffered and non-ECC type)
GraphicsIntel® HD Graphics 520
Triple display with 1x VGA, 1x DVI-D and 1x CDS interface
AudioRealtek® ALC888-GR
High Definition Audio
I/O Interface1x VGA (Up to 1920 x 1080 @ 60Hz), DB-15
1x DVI-D (Up to 1920 x 1080 @ 60Hz)
1x CDS Interface, Compact PCI Connector
2x GbE LAN (Support WoL, Teaming, Jumbo Frame and PXE), RJ45
- GbE1: Intel I219LM
- GbE2: Intel I210
2x PoE+ (with Optional CFM PoE Module)
- Comply with IEEE 802.3at, Offers Up to 25.5W Per Port
6x RS-232/422/485 with Auto Flow Control (Support 5V/12V), DB9
4x USB 3.0, Type-A
1x USB 2.0, Type-A
16x Isolated DIO (8x DI/8x DO), 20-Pin Terminal Block
1x Line-out & 1x Mic-in, Phone Jack 3.5mm
1x Power On/Off Switch
1x Reset Button
1x AT/ATX Switch
1x Remote Power On/Off Connector, 2-Pin Terminal Block
1x External FAN Connector, 4-Pin Terminal Block
Storage2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3)
2x mSATA (One Shared by Mini-PCIe Socket) (Gen2)
1x CFast Socket (Gen3)
Expansion1x CFM PoE interface
1x CFM IGN interface
1x PCI or 1x PCIex4 Expansion slot
Optional Riser Card: 1x PCI, 1x PCIx4
Support Maximum dimension of add-on card
(H x L): 100mm x 200mm
2x Full-size Mini-PCIe Socket
1x Universal I/O Bracket
1x SIM Socket
4x Antenna Hole
Other FunctionSupport CDS Technology
Support CFM Technology
Support Instant Reboot Technology (0.2 sec)
Support Power Ignition Sensing (IGN)
Support OSD Function
(LCD On/Off, Brightness Up, Brightness Down for CDS Display Module)
Internal Speaker AMP 2W + 2W
SuperCap Integrated
Watchdog Timer:
Software Programmable Supports 256 Levels System Reset
Power RequirementSupport AT/ATX Power Mode
Power Input Voltage 9~48VDC
One 3-pin Terminal Block Connector
Power Adapter AC/DC 24V/5A 120W or 24V/9.2A 220W (Optional)
PhysicalDimension (WxHxD): 450 x 350 x 106.5 mm
Weight: 8.82 kg
Front Panel Construction: Flat Rugged Aluminum Die-Casting Bezel
Support Panel / VESA / *Rack Mounting (*with optional mounting kit)
Fanless Design
Jumper-less Design
ProtectionReverse Power Input Protection
Over Voltage Protection:
Protection Range: 51~58V
Protection Type: shut down operating voltage, re-power on at the preset level to recover
Over Current Protection: 15A
ESD Protection: +/-8kV (air), +/-4kV (contact)
Surge Protection: 2kV
Operating SystemWindows® 10
Windows® 8.1
Windows® 7
EnvironmentOperating Temperature: -20°C to 70°C
(With extended temperature peripherals; Ambient with air flow
According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
Storage Temperature: -20°C to 70°C
Relative Humidity: 80% RH @ 40°C (Non-condensing)
Shock: Operating, 15 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-64)
Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes
IP Level: IP65 Compliant Front Panel
EMC: CE, FCC Class A
ORDERING INFORMATION
Available Models
Model No.Product Description
CS-117C-R10/P2002E-i5-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x Reserved Expansion Slot
CS-117C-R10/P2002E-i5-E4-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x PCIe x4 Expansion Slot
CS-117C-R10/P2002E-i5-PI-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-117C-R10/P2002E-i3-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x Reserved Expansion Slot
CS-117C-R10/P2002E-i3-E4-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x PCIe x4 Expansion Slot
CS-117C-R10/P2002E-i3-PI-R1017" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x PCI Expansion Slot

Package Checklist
√Panel PC x 1√Panel Mounting Kit x 1
√Utility DVD Driver x 1√Fan Terminal Block Connector x 1
√Power Terminal Block Connector x 1√DIO Terminal Block Connector x 2
√Screw Pack x 1√Power On/Off Terminal Block Connector x 1

Optional Modules
Model No.Description
CFM-IGN100CFM Module with Power Ignition Sensing Control Function, 12V/24V Selectable (41 x 35 mm)
CFM-PoE101PoE Control Function Module, Individual Port 25.5W (50 x 44 x 33 mm) (For CS-100/P2002E only)
MEC-COM-M212-0503Mini-PCIe Module with 2x COM Ports, 2x Universal Brackets (154 x 17 mm)
MEC-COM-M334-0504Mini-PCIe Module with 4x RS-232/422/485 Serial Ports,1x Universal Bracket (154 x 17 mm)
MEC-FIR-M003-0501Mini-PCIe Module with 1x 1394A Port, 2x 1394B Ports, 1x Universal Bracket (154 x 17 mm)
MEC-LAN-M102-30/UB0511Mini-PCIe Module with 2x LAN Ports, 2x 30cm cable / 1x Universal Bracket with 2x RJ45 Cutout for P2000 Series
MEC-USB-M002-0514Mini-PCIe Module with 2x USB 3.0 Ports, 1x Universal Bracket (154 x 17 mm)
RC-E4-01Riser Card with 1x PCIex4 Slot (For CS-100/P2002E only)
RC-PI-01Riser Card with 1x PCI Slot (For CS-100/P2002E only)

Optional Accessories
Model No.Description
GST220A24-CINAdapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm Pitch, with TUBES, GST220A24-CIN
GST120A24-CINAdapter AC/DC 24V 5A 120W, GST120A24-CIN, wide temp (-30°C ~ +70°C), level VI
SL2-SL3US 2 heads power cord, US B type to IEC C13,SVT 18AWG/3C Black 1.8M
SL6-SL3EU 2 heads power cord, EU G type to IEC C13,H05VV-F 0.75mm2/3G Black 1.8M
QP026-SL3UK 2 heads power cord, UK I type to IEC C13,H05VV-F 0.75mm2/3G Black 1.8M
URM01Universal 19" Rack Mount Kit for Industrial Panel PC & Industrial Monitor
